Redis University: Redis Search Engine

This post is my personal notes on the Redis Search Engine course from Redis University. It covers the basics of the Redis Query Engine, including how to create indexes, perform queries, and use advanced features like aggregation and spellcheck.

To make the most of the commands and examples in this post, set up your Redis environment and load the data by following the instructions in the GitHub Repository. Once set up, create the index by running the following command in the Redis CLI:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
FT.CREATE books-idx
    ON HASH PREFIX 1 ru203:book:details:
    SCHEMA
        isbn TAG SORTABLE
        title TEXT WEIGHT 2.0 SORTABLE
        subtitle TEXT SORTABLE
        thumbnail TAG NOINDEX
        description TEXT SORTABLE
        published_year NUMERIC SORTABLE
        average_rating NUMERIC SORTABLE
        authors TEXT SORTABLE
        categories TAG SEPARATOR ";"
        author_ids TAG SEPARATOR ";"

Querying Structured Data with Redis Query Engine

Exact Matches with `TAG`

The TAG field type is ideal for exact string matches, offering high efficiency.

1
2
FT.SEARCH books-idx "@isbn:{9780393059168}"
FT.SEARCH books-idx "@author_ids:{690}" RETURN 1 title

To query strings containing special characters (,.<>{}[]"':;!@#$%^&*()-+=~), escape them with a backslash (\).

1
FT.SEARCH books-idx "@authors:{j\\. r\\. r\\. tolkien}"

Numeric Range Queries with `NUMERIC`

Use the NUMERIC field type for numerical data, enabling powerful range queries. The range syntax is [min max], inclusive of both endpoints. Use -inf or +inf for unbounded ranges. To exclude an endpoint, add ( before the value.

1
2
3
4
FT.SEARCH books-idx "@average_rating:[4.5 5.0]" RETURN 1 title
FT.SEARCH books-idx "@average_rating:[4 +inf] @published_year:[2015 +inf]" RETURN 1 title
FT.SEARCH books-idx "@average_rating:[-inf 3] @published_year:[-inf (2000]" RETURN 1 title
FT.SEARCH books-idx "@average_rating:[4.5 5.0] @published_year:[(2015 +inf]" RETURN 1 title

Full-Text Search with `TEXT`

Queries without a specified field default to full-text search across all TEXT fields.

1
2
3
4
5
6
7
FT.SEARCH books-idx "dogs|cats"
FT.SEARCH books-idx "dogs -cats" RETURN 1 title
FT.SEARCH books-idx "@authors:'rowling' @title:'goblet'"
FT.SEARCH books-idx "@authors:\"rowling\" | @title:\"potter\""
FT.SEARCH books-idx "@authors:tolkien -@title:ring"
FT.SEARCH books-idx “@categories:{Philosophy} @published_year:[-inf 1975] -@authors:'Arthur Koestler'”
FT.SEARCH books-idx "@authors:'Arthur Koestler' | @authors:'Michel Foucault'"

TEXT vs. TAG: TEXT fields undergo stemming (e.g., “running” becomes “run”), allowing broader matches. TAG fields provide exact string matches without stemming.

Sorting Results with `SORTABLE`

The SORTABLE option allows you to sort query results by a specified field (NUMERIC, TEXT, or TAG). Note that sorting is limited to one field at a time.

1
2
3
4
5
6
7
8
FT.CREATE books-idx
  ON HASH PREFIX 1 ru203:book:details:
  SCHEMA
    ...
    published_year NUMERIC SORTABLE
    ...

FT.SEARCH books-idx "@published_year:[2018 +inf]" SORTBY published_year DESC

Using SORTBY on a field not marked SORTABLE will cause an error.

Limiting Results with `LIMIT`

LIMIT controls the number of results returned, taking a zero-based offset and a count.

1
FT.SEARCH books-idx "@authors:Agatha Christie" SORTBY published_year LIMIT 0 5

Full-text search with Redis Query Engine

Stemming

TEXT fields in RedisSearch store the root form of words (stemming), improving search results by matching different word forms (e.g., “running” matches “run”).

> FT.SEARCH books-idx "@title:running" RETURN 1 title
1) "14"
2) "ru203:book:details:9780451197962"
3) 1) "title"
   2) "The Running Man"
4) "ru203:book:details:9780385315289"
5) 1) "title"
   2: "Running from Safety"
6) "ru203:book:details:9780679722946"
7) 1) "title"
   2) "Running Dog"
8) "ru203:book:details:9780345461612"
9) 1) "title"
   2) "Running from the Deity"
10) "ru203:book:details:9780330281720"
11) 1) "title"
    2) "Running in the Family"
12) "ru203:book:details:9780590317672"
13) 1) "title"
    2) "Run"
14) "ru203:book:details:9780439650366"
15) 1) "title"
    2) "Werewolves Don't Run For President"
16) "ru203:book:details:9781400033829"
17) 1) "title"
    2) "Who Will Run the Frog Hospital?"
18) "ru203:book:details:9780340769201"
19) 1) "title"
    2) "Running Away from Richard"
20) "ru203:book:details:9780671024185"
21) 1) "title"
    2) "Morgan's Run"

Prefix Search

Prefix search finds words starting with a specific prefix.

Be aware that less specific queries can impact performance.

1
2
FT.SEARCH books-idx "atwood hand*"
FT.SEARCH books-idx "agat* orie*"

Summarizing and Highlighting Results

SUMMARIZE provides a brief description of search results, returning the first LEN characters and FRAGS (number of fragments) from specified FIELDS.

1
FT.SEARCH books-idx agamemnon SUMMARIZE FIELDS 1 description FRAGS 3 LEN 25

HIGHLIGHT emphasizes search terms within results for better readability.

1
2
FT.SEARCH books-idx agamemnon SUMMARIZE FIELDS 1 description FRAGS 3 LEN 25 HIGHLIGHT
FT.SEARCH books-idx agamemnon SUMMARIZE FIELDS 1 description FRAGS 3 LEN 25 HIGHLIGHT FIELDS 1 description

Aggregation with Redis Query Engine

The FT.AGGREGATE command performs calculations like counting, summing, or averaging on data, useful for large datasets.

Counting Results with `COUNT`

COUNT is used to count the number of records that match a specific query.

1
2
FT.SEARCH books-idx * LIMIT 0 0
FT.AGGREGATE books-idx * GROUPBY 0 REDUCE COUNT 0 AS total

Grouping Data with `GROUPBY`

GROUPBY is used to group the results by a specific field.

1
2
FT.AGGREGATE books-idx * GROUPBY 1 @authors REDUCE COUNT 0 as published_books
FT.AGGREGATE books-idx marauder GROUPBY 2 @published_year @average_rating

Performing Calculations with `REDUCE`

REDUCE executes calculations on grouped results. Common functions include COUNT, COUNT_DISTINCTISH, SUM, AVG, MIN, and MAX.

1
2
FT.AGGREGATE books-idx * GROUPBY 1 @categories REDUCE COUNT 0 as total SORTBY 2 @total DESC
FT.AGGREGATE books-idx tolkien GROUPBY 0 REDUCE AVG 1 @average_rating as avg_rating

Applying Custom Functions with `APPLY`

APPLY allows custom functions for complex calculations not supported by built-in reduce functions.

1
2
3
4
5
FT.AGGREGATE books-idx *
   APPLY "split(@authors, ';')" AS authors_list
   GROUPBY 1 @title
   REDUCE COUNT_DISTINCT 1 authors_list AS authors_count
   FILTER "@authors_count==2"

Advanced Redis Query Engine Topics

Partial Indexing

Partial indexing indexes only a subset of fields, useful for large documents where only specific fields require searching.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
FT.CREATE books-older-idx
   ON HASH PREFIX 1 ru203:book:details:
   FILTER "@published_year<1990"
   SCHEMA
      isbn TAG SORTABLE
      title TEXT WEIGHT 2.0 SORTABLE
      subtitle TEXT SORTABLE
      thumbnail TAG NOINDEX
      description TEXT SORTABLE
      published_year NUMERIC SORTABLE
      average_rating NUMERIC SORTABLE
      authors TEXT SORTABLE
      categories TAG SEPARATOR ";"
      author_ids TAG SEPARATOR ";"

Adjusting Result Scores with `WEIGHT`

The WEIGHT option allows you to adjust the score of results, boosting the relevance of certain fields.

1
FT.SEARCH books-idx "((@categories:{History}) => { $weight: 10 } greek) | greek" RETURN 2 title categories

Handling Punctuation in Fields

If you wanna do matching on a field that contains punctiation, you need to proccess this field by escaping the punctuation characters.

1
2
3
4
5
6
7
HMSET ru203:user:details:1000
   first_name "Andrew"
   last_name "Brookins"
   escaped_email "a\\.m\\.brookins\\@example\\.com"
   user_id "1000"

FT.SEARCH users-idx "@escaped_email:a\\.m\\.brookins\\@example\\.com"

Spelling Error Correction

The fuzzy operator (%) enables fuzzy search for spelling errors, with the number of % signs determining the maximum Levenshtein distance.

1
FT.SEARCH books-idx "%adress%" HIGHLIGHT

Alternatively, SPELLCHECK provides suggestions for misspelled words. A common practice is to check if a query returns results, and if not, use SPELLCHECK. This feature supports languages like English, French, German, Italian, and Spanish. I will cover how to customize the spellcheck dictionary in a future post.

1
2
3
4
5
> FT.SPELLCHECK books-idx wizrds
1) 1) "TERM"
   2) "wizrds"
   3) 1) 1) "0.0014684287812041115"
         2) "wizards"
